TP-Link 5GHz 300Mbps 13dBi Outdoor CPE (CPE510)

Description

The TP-Link CPE510 is a 5GHz 300Mbps 13dBi Outdoor CPE designed for long-distance wireless networking applications. It is ideal for point-to-point, point-to-multipoint, and outdoor Wi-Fi coverage applications.

Key Features:

• High-Gain Antenna: Equipped with a built-in 13dBi 2×2 dual-polarized directional MIMO antenna, ensuring efficient wireless transmission over long distances.
• Adjustable Transmission Power: Offers transmission power settings up to 27dBm/500mW, allowing for flexible coverage adjustments based on specific requirements.
• Long-Range Transmission: Optimized for wireless data transmission over distances exceeding 15km, making it suitable for remote deployments.
• Pharos MAXtream TDMA Technology: Enhances performance in throughput, capacity, and latency, especially beneficial in point-to-multipoint scenarios.
• Multiple Operating Modes: Supports various modes including Access Point, Client, Repeater, AP Router, and AP Client Router (WISP), providing versatility in deployment.
• Centralized Management: Utilizes TP-Link’s Pharos Control software for centralized management, simplifying network administration.
• Passive PoE Support: Includes a Passive PoE adapter supporting up to 60 meters (200 feet) of Power over Ethernet deployment, facilitating flexible installation.

Technical Specifications:

• Wireless Standards: IEEE 802.11a/n
• Frequency: 5GHz
• Data Rate: Up to 300Mbps
• Interface: 1× 10/100Mbps Shielded Ethernet Port (LAN0, Passive PoE in)
• Antenna Beam Width: 45° (Horizontal), 30° (Vertical)
• Dimensions: 224 × 79 × 60 mm
• Weatherproofing: IPX5-rated enclosure
• Surge Protection: 15kV ESD and 6kV Lightning Protection
• Operating Temperature: -30°C to 70°C

Package Contents:

• CPE510 Unit
• Passive PoE Adapter
• Power Cord
• Mounting Kits
• Installation Guide

For more detailed information, you can refer to the official product page: TP-Link CPE510 5GHz 300Mbps 13dBi Outdoor CPE.
